TQCL1250 Tire Bead Cutter Debeader

5 0 Reviews
Pull-out the tire double bead steel wire at room temperature in order to extend the blades lifespan in shredding and crushing process.
Price: $ 0

Equipment Features:

The hydraulic station,hydraulic cylinder,control cabinet and so on etc fixed on the framework of equipment,so the whole equipment is simple structure,nice appearance,easily transported and installed.Adopted vane pump supply oil lower the noise during the equipment running and pull-out the steel wire as normal speed during the press cylinder working,which improve the working efficiency and lifespan of hydraulic parts.Used working way of unladen hook reach out,load bead cutted in slow speed and hydraulic bead wire pulled out,which improve the production efficiency. Reduce labor intensity via using the lift device.

Main technical spec

Equipment model TQCL1250
Motor power(Kw) 15
System pressure(MPa) <20
Tire size (mm) ≤1200
Max. run distance of extracting cylinder(mm) 1250
Max. run distance of pressing cylinder(mm) 350
 Capacity (Pcs/h) 30-45
Cutter blade lifespan(h) 6000
Hook lifespan(h) Surfacing and grinding repeatedly
Size(L×W×Hmm) 4300×1030×1550
Equipment weight(Kg) 2700
